Speeding Up Windows

1. Disable Indexing Services
Indexing Services is a program that perform index to your computer. When you do a search for something on your computer, it will search faster by scanning the index lists but this system service is completely unnecessary. To disable do the following:

• Go to My Computer
• Right click on C: drive
• Click Properties
• Uncheck “Allow Indexing Service to index this disk for fast file searching”
• Apply to all files and folders
• If Windows prompt that file is in use, click ignore to all

2. Optimise Display Settings
Windows XP original theme visual items can waste system resources. To optimise:

• Go to Start
• Click Settings ( if you can’t find it, go to the next step)
• Click Control Panel
• Click System
• Click Advanced tab
• In the Performance tab click Settings
• Then select Adjust for best performance
• Click Apply and Ok
• Windows will take 1-3 minutes to implement the new changes.

3. Speedup Folder Browsing
You may have noticed that everytime you open my computer to browse folders that there is a slight delay. This is because Windows XP automatically searches for network files and printers everytime you open Windows Explorer. To fix this and to increase browsing significantly:

• Open My Computer
• Click on Tools menu
• Click on Folder Options
• Click on the View tab.
• Uncheck the Automatically search for network folders and printers check box
• Click Apply
• Click Ok
• Reboot your computer


4. Optimise Your Pagefile
If you give your pagefile a fixed size it saves the operating system from needing to resize the page file.

• Right click on My Computer and select Properties
• Select the Advanced tab
• Under Performance choose the Settings button
• Select the Advanced tab again and under Virtual Memory select Change


• Highlight the drive containing your page file and make the initial Size of the file the same as the Maximum Size of the file.



• Click ok and restart computer

5. Disable Prefetch on Low Memory Systems
Prefetch is designed to speed up program launching by preloading programs into memory - not a good idea is memory is in short supply, as it can make programs hang. To disable prefetch:

• Click ‘Start’ then ‘Run’
• Type in ‘Regedit’ then click ‘Ok’
• Navigate to 'HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\SessionManager\Memory Management\PrefetchParameters\’
• Right-click on “EnablePrefetcher” and set the value to ‘0′
• Reboot.

6. Improve XP Shutdown Speed
This tweak reduces the time XP waits before automatically closing any running programs when you give it the command to shutdown.

• Go to Start then select Run
• Type ‘Regedit’ and click ok
• Find ‘HKEY_CURRENT_USER\Control Panel\Desktop\’Select ‘WaitToKillAppTimeout’
  Right click and select ‘Modify’
• Change the value to ‘1000′
• Click ‘OK’
• Now select ‘HungAppTimeout’
• Right click and select ‘Modify’
• Change the value to ‘1000′
• Click ‘OK’
• Now find ‘HKEY_USERS\.DEFAULT\Control Panel\Desktop’
• Select ‘WaitToKillAppTimeout’
• Right click and select ‘Modify’
• Change the value to ‘1000′
• Click ‘OK’
• Now find ‘HKEY_LOCAL_MACHINE\System\CurrentControlSet\Control\’
• Select ‘WaitToKillServiceTimeout’
• Right click and select ‘Modify’
• Change the value to ‘1000′
• Click ‘OK’

7. Make Your Menus Load Faster
This is one of my favourite tweaks as it makes a huge difference to how fast your machine will ‘feel’. What this tweak does is remove the slight delay between clicking on a menu and XP displaying the menu.

• Go to Start then Run
• Type ‘Regedit’ then click ‘Ok’
• Find “HKEY_CURRENT_USER\Control Panel\Desktop\”
• Select “MenuShowDelay”
• Right click and select “Modify’
• Reduce the number to around “100″

8. Speedup Folder Access - Disable Last Access Update
If you have a lot of folders and subdirectories on your computer, when you access a directory XP wastes a lot of time updating the time stamp showing the last access time for that directory and for ALL sub directories. To stop XP doing this you need to edit the registry. If you are uncomfortable doing this then please do not attempt.

• Go to Start and then Run and type “regedit”
• Click through the file system until you get to
• HKEY_LOCAL_MACHINE\System\CurrentControlSet\Control\FileSystem”
• Right-click in a blank area of the window on the right and select ‘DWORD Value’
• Create a new DWORD Value called ‘NtfsDisableLastAccessUpdate’
• Then Right click on the new value and select ‘Modify’
• Change the Value Data to ‘1′
• Click ‘OK’

SAP R/3 Tips and Tricks - by Ricardo Fernandes de Miranda

Lately I found a very helpful SAP website.
Resources from: http://www.sapfans.com/sapfans/saptips.htm

•
  Logging
  on without being authorized



Client
066 usually exists in a SAP system due to EarlyWatch services. Often this
client does not have master users. If it is true, anyone can log into the
system using the client 066, user SAP*, and password PASS. Enjoy yourself.

•
  Special
  copy and paste



Click
on the area and press CTRL+Y. It allows you to copy many lines at once
and paste them afterwards.

•
  Long messages
  on footer



Click
on the message and hold the mouse button. After moving the mouse to the
left side.

•
  Direct
  input logs



The
transaction BMV0 (direct input logs) shows all direct input logs.

•
  Graphics
  on SAPscript



The
program RSTXLDMC can be used to upload graphics (file extension .tif on
PC files) into individual standard text.

•
  Adding
  icons



Check
the icon code using transaction ICON. A technical view can be found at
the include named «ICON». Sequences of characters begin and
finish with the symbol @. Even plain files under operating system can contain
those strings.

•
  Filling
  up an empty date field quickly



Strike
the key F4 (or click on matchcode symbol) and press ESCAPE. The current
date is automaticly set.

•
  Setting
  up module FI/CO without using IMG



Almost
all parameters can be set using the transactions ORFA (Asset Accounting),
ORFB (Financial Accounting), and ORKS (Cost Center Accounting).

•
  Displaying
  check object when not authorized



Soon
after the lock try to access the transaction SU53. It reports the last
objects verified and also the respective values.

•
  Table
  analyses between two systems



The
contents of a table between two systems can be checked through the transaction
OY19.

•
  Correction
  and transport system



The
transaction SE10 provides the easiest way to manage any request/transport
and corrections.

•
  General
  command field formats
































































/n	Skip to the next record if you are processing one batch input session
/bend	Cancel a batch input foreground process
/nend	Close all R/3 sessions and logoff
/nxxxx	Call the transaction xxxx in the same session
/o	Generate a session list
/oxxxx	Call the transaction xxxx in an additional session
/i	Delete the current session
/h	Turn the debug mode on
/$tab	Reset all buffers (for System Administrators)
/$sync	Synchronize instances buffers (for System Administrators)




•
  Report command field formats














































%pri	Print the current report
%pc	Download the current report
%sc	Call the find function
p+	Go to the next page
p-	Go to the previous page
p++	Go to the last page
p--	Go to the first page




•
  Helpful reports
































































RSCLTCOP	Copy tables across clients
RSAVGL00	Table adjustment across clients
RSINCL00	Extended program list
RSBDCSUB	Release batch-input sessions automaticly
RSTXSCRP	Transport SAPscript files across systems
RSORAREL	Get the Oracle Release
RGUGBR00	Substitution/Validation utility
RSPARAM	Display all instance parameters
RSUSR003	Check the passwords of users SAP* and DDIC in all clients
RSUSR006	List users last login




•
  Unconditional mode when importing
  or exporting a request/transport



Run the command R3trans
-u under user «SysID»adm.

•
  Main return codes of tp
  program


































0	Successfully done
4	Warnings occurred
8	Errors occurred
12	Fatal errors occurred
16	Internal errors occurred




•
  Scheduling of system maintenance
  jobs




























RSBTCDEL	Clean the old background job records
RSDBCREO	Clean batch input session log
RSPO0041	Removing old spooling objects
RSSNAPDL	Clean the old ABAP error dumps




•
  Locking the whole system



Using the command tp
locksys «SysID» only the user SAP* will be allowed to login.
The command tp unlocksys «SysID» cancels the lock.

•
  Connection between SAP R/3 and
  operating system



The command sapevt
can be used to trigger an event from the operation system. Thus, a job
previously defined within R/3 will be released.

•
  SQL code help



Run the command oerr
ora «error number» under user ora«SysID».

•
  Oracle import and export explanations



Run the command imp help=yes
under user ora«SysID». This format can also be used with exp,
impst, and expst.

SAP
R/3 Hints
TOP

---

Of
course it does not guarantee a successful implementation. It is a great
deal of summed up aid, though.

•
  Team integration
  has to be enhanced



•
  Set high
  standards of performance for implementation team



•
  IT teams
  and users have to work closely during the implementation



•
  New ways
  of thinking and acting must not be discarded



•
  Do not
  underestimate the user training needs



•
  Project
  management should be on the critical list



•
  The nearest
  SAP branch should be your partner



•
  Consultants
  are not always the key to succeed



•
  Consultants
  are a good source of knowledge. On the other hand, letting them make configuration
  changes the transfer of knowledge will be harmed



•
  Foreign
  consultants usually do not know country-specific details



•
  Deepening
  your basis knowledge is always useful



•
  Avoid
  changing standard R/3 objects as much as possible



•
  Always
  follow the SAP rules to give names to your own objects



•
  Establish
  SAP connection as soon as possible



•
  Exchange
  information with other companies



•
  Focus
  on interfaces with non-R/3 applications



•
  Plan the
  whole environment carefully (servers, network, protocols, etc.)



•
  Development
  and production environment should be totally independent

SAP
R/3 Enhancements
TOP

---

Some
special features allow you wide modifications without changing standard
SAP R/3 objects. Those
techniques are not as widespread as they should be. In fact they are powerful
tools.

•
  Field
  exit



After
entering a value in a field, it can be checked through a field exit. The
system makes the field value available to be checked and changed in an
ABAP/4 function.

•
  User exit



Points
previously set in the system that let you evaluate data. The fields available
are also previously defined by SAP. All fields value available can be checked
in an ABAP/4 program.

•
  Validation



It
allows solid data entry regarding special rules. According to previous
rules, the system can evaluate an entry and a message can appear on the
user's terminal if a check statement is not met. A validation step contains
prerequisite statement and check statement. Both of them are defined using
Boolean Logic or calling an ABAP/4 form.

•
  Substitution



Fields
contents can be changed using substitution. When data are being entered,
the data can be substituted by another value regarding rules previously
defined. A substitution step contains prerequisite statement, substitution
value and substitution exit. All of them are defined using Boolean Logic
or calling an ABAP/4 form.

•
  Set



Values
or ranges of values are specified under a set name. Sets are easier to
create and maintain instead of using tables. They give you more flexibility
when maintaining your system.

•
  Key words



It
allows changes on field description according to data element. The short
key word used on most screen to identify the corresponding field contents
can be changed too.

•
  Requirements
  & formulas



ABAP/4
forms that can be used to handle pricing procedures, rounding rules, copy
and data transport Sales activities.

SAP
R/3 Troubleshooting
TOP

---

•
  System
  gets stuck



It
happens mostly when archive area is overloaded. Run the program brarchive
with deletion option to release disk space.

•
  Short
  dump



Not
always the problem is technical. Try to create all SAPoffice users through
transaction SO32 (create all SAPoffice users) and review your application
data carefully.

•
  Field
  exits are completely ignored



Make
sure your SAP profile parameter contains the option abap/fieldexit = yes.

•
  Transaction
  SE16 (table contents) does not work properly



Make
usage of the menu option to regenerate the display program. You can also
try changing key words according to field names. Choose Option -> Parameters
users.

•
  Rollback
  segments are too small



Before
increasing up the rollback segment size you should verify your programs.
Very often the problem belongs to them.

•
  Files
  for rollback segments are already enormous



Check
the rollback segments configuration. It has to match the allocated area
on tablespaces. Changes have to be done using Oracle tools.

•
  Extended
  help under windows does not link correctly



Check
the file sapdoccd.ini under your presentation server. It must be
present in the main windows directory and should assign to help files directory.

•
  Release
  procedure with classification does not work



As
a matter of fact you are not the only one to notice it. It hardly works.
Before using release strategy you should apply all notes on OSS. Pray might
be useful too.

•
  Transport
  area is overloaded



The
command tp clearold «SysID» cleans up the transport
area according to parameters previously set on the plain file TPPARAM.

•
  Instance
  does not establish communication



Shutdown
the whole system and check the Interprocess Communication Facilities. Any
references should be found. Either the command IPCS (UNIX) or showipc
«INSTANCE NUMBER» (SAP) show all message queue, semaphore
set and shared memory identifier. Before trying again you have to remove
them using the command IPCRM (UNIX) or cleanipc «INSTANCE
NUMBER» (SAP).

Note:

Research based on version 3.0f under Unix, Oracle data base and Windows.

SAP
R/3 Security
TOP

---

Simple
changes can rise your system security. Usage of SAProuter is a good choice
when correctly implemented. Login through SAP LogonPad (from version 3.0f
onwards) improve the access control. SAP profile parameters shall also
contain:

•
  Rdisp/gui_auto_logout
  = 1800



The
user connection is closed after 30 minutes without usage.

•
  Login/fails_to_session_end
  = 3



After
3 wrong password the connection is automaticly closed.

•
  Login/fails_to_users_lock
  = 5



After
5 wrong password the user is locked.

•
  Login/min_password_lng
  = 6



Password
length at least 6 characters.

•
  Login/password_expiration_time
  = 90



Password
expires after 3 months.

Note:	I do not have to waste my time telling you to change all default passwords.
	Make sure to have the master user SAP* in all clients otherwise anyone can log into your system. See Tips & Tricks.

SAP
R/3 Programming
TOP

---

Indeed
these powerful ABAP/4 functions are very interesting and can bring some
advantages. Improve your home development easily. They belong to standard
objects and should never be changed.

•
  Ws_upload



Transfer
files from the frontend to the application server.

•
  Ws_download



Transfer
files from the application server to the frontend.

•
  Ws_excel



Download
files at the frontend in excel format.

•
  Bp_joblog_read



Fetch
job log executions.

•
  Rs_send_mail_for_spoollist



Send
message from ABAP/4 program to SAPoffice.

•
  Bp_event_raise



Trigger
an event from ABAP/4 program.

•
  So_wind_spool_list



Browse
printer spool numbers according to user informed.

•
  So_spool_read



Fetch
printer spool according to the spool number informed.

•
  G_set_get_all_values



Fetch
values from a set.

•
  Rzl_sleep



Hang
the current application from 1 to 5 seconds.

•
  Rzl_submit



Submit
a remote report.

•
  Ws_execute



Execute
an external program on the presentation server.

•
  Ws_file_delete



Delete
file at the frontend.

•
  Ws_volume_get



Get
the label from a frontend device.

•
  Ws_msg



Create
a dialog box in which you display an one-line message.

•
  Popup_to_display_text



Create
a dialog box in which you display a two-line message.

•
  Popup_to_confirm_step



Create
a dialog box in which you make a question whether the user wishes to perform
the step.

•
  Popup_to_confirm_with_message



Create
a dialog box in which you inform the user about a specific decision point
during an action.

•
  Popup_to_confirm_with_value



Create
a dialog box in which you make a question whether the user wishes to perform
a processing step with a particular object.

•
  Popup_to_confirm_loss_of_data



Create
a dialog box in which you make a question whether the user wishes to perform
a processing step with loss of data.

•
  Popup_to_decide



Create
a dialog box in which you require the user between the two processing alternatives,
or to cancel the action.

•
  Popup_to_decide_with_message



Create
a dialog box in which you inform the user about a specific decision point
via a diagnosis text.

Note:

These functions have been used and have worked as well as they were supposed to do.

SAP
R/3 Glossary
TOP

---

Information
Technology has many key words and SAP
R/3 has introduced many others. In order to understand even better
this field you should keep in mind those terms.

•
  ALE (Application
  Link Enabling)



It
provides integration for separate R/3 systems, keeping full interaction.
This makes possible distributed enterprise applications.

•
  Application
  server



The
application server is used to run the business application programs in
the R/3 client/server concept. The application modules are loaded from
the data base server to the application server as required. Thus the application
server requires only storage capacity to accommodate UNIX, Swapping and
the SAP runtime environment.

•
  Batch
  Input



A
technique to input data safely. It ensures application data integrity for
background interfaces. It pretends to be someone typing. See also direct
input.

•
  CATT (Computer
  Aided Test Tool)



It
allows you to combine and automate sequences of repeatable transactions
in test procedures. CATT reduces the number of manual tests, and forces
you to test systematically, defining input values and expected test results.

•
  CCMS (Computer
  Center Management System)



It
allows you to monitor, control and configure your R/3 system. This toolset
lets you analyze and distribute client workloads and report on resource
consumption for system components.

•
  Central
  System



In
an R/3 central system, both application and data base software are run
on one computer.

•
  Client



In
commercial, organizational and technical terms, a self-contained unit in
an R/3 system with separate master records and its owns set of tables.

•
  Client/Server
  System



Client/server
systems are structured modularly, with components working in a sender/receiver
relationship. Software components can also be used in a client/server relationship.

•
  Communication
  Server



It
provides the connection between local area and wide area networks and may
be either a router, a bridge or a gateway. In R/3 installations, the communication
server must support the TCP/IP protocol over wide area networks.

•
  Company
  code



The
smallest organizational unit for which a complete self-contained set of
accounts can be drawn up for purposes of external reporting. This involves
recording all relevant transactions and generating all supporting documents
for legally-required financial statements, such as balance sheets and profit
and loss statements.

•
  Computer
  type



The
R/3 system supports various computer types of SAP's platform partners,
such as Bull, DEC, IBM and HP. The suitability of a particular computer
type depends on sufficient CPU performance.

•
  CPI-C
  (Common Programming Interface-Communications)



Common
Programming Interface of Communication has been introduced by IBM as a
high-level interface to SNA/LU6-2. CPI-C has become the subject of the
X/Open stardarlization and is used by SAP to facilitate program-to-program
communication between R/3 and external system. SAP offers CPI-C libraries
based on TCP/IP.

•
  Correction



It
contains all the objects that a developer has changed or created. It also
controls customizing that has been maintained.

•
  CSP



A
system to help SAP employees to give comprehensive support to their clients.

•
  Data base
  server



The
data base server stores the SAP application programs and data in the R/3
client/server concept. It also handles the SAP update program and batch
jobs.

•
  Direct
  Input



A
recent technique to input data safely. It ensures application data integrity
for background interfaces. See also batch input.

•
  Dispatcher



The
system R/3 agent that identifies the type of task (on-line, update, batch,
etc.) and sends the job to an idle work process.

•
  EarlyWatch



It
is a service that entails having your R/3 installation regularly inspected
by SAP employees, in other to ensure high system availability and high
data throughput at all time.

•
  Ethernet



It
is a LAN architecture using bus topology. The transmission speed is 10
MBit/s.

•
  FDDI (Fiber
  Distributed Data Interchange)



It
is a local high-speed network with ring topology based on light wave conductors.
The transmission speed is 100 MBit/s.

•
  Field
  status



Indicator
that specifies whether a field can take an entry in the entry screen or
if it must be filled.

•
  Firewall



It
is a means of controlling access through a public network to a private
network.

•
  FTP (File
  Transfer Protocol)



It
is the most commonly used file transmission protocol of the TCP/IP protocol
family.

•
  GUI (Graphic
  User Interface)



A
graphical interface used by SAP environment as part of the three tiers.
It is normally called user frontend.

•
  IDES (International
  Demonstration and Education System)



It
is a model of an international firm. It is a separate demonstration and
education system for speeding up the pilot process.

•
  IMG (Implementation
  Management Guide)



It
is a hierarchical structure that reflects the R/3 component hierarchy and
contains every configuration activity. Released from version 3.0 onwards.

•
  Instance



It
means application server and each one has its own set of work processes.

•
  IDoc (Intermediate
  Document)



An
IDoc is a data container for data exchange between SAP systems or between
an SAP system and an external system.

•
  ITS (Internet
  Transaction Server)



It
links the R/3 application server with one or more Web servers, thus enabling
the R/3 to communicate with the Internet.

•
  Kernel



It
means a standard core previously configured. A set of default parameters
delivered with the system.

•
  LAN (Local
  Area Network)



It
is a network foa a tightly limited area with high level data transmission
performance. Common LANs include Ethernet, Token Ring and FDDI. These LANs
support different transport protocols, such as TCP/IP and IPX.

•
  Matchcode



A
tool for finding specific record. It is made up of search terms. It is
used to find possible entries for an input field.

•
  Number
  range



A
range of numbers that are laid down per file for the assignment of document
numbers. It can be internal (carried out automatically by the system) or
external (carried out manually by the user).

•
  OLE



It
is a technique introduced by Microsoft to incorporate objects of one application
into another.

•
  OSS (Online
  Service System)



SAP's
Online Service System offers fast and effective help for R/3 System problems.
It is also the basic element of communications between customers, partners,
and SAP.

•
  Repair



It
contains all the objects that a developer has changed but the originals
of the objects are located in another system.

•
  RFC



A
way to implement communication between application programs via Abap/4
function call.

•
  Semaphores



When
a work process locks a resource, it sets a semaphore. Another work process
that also wants to access it must then wait.

•
  SysID



A
set of three letters or number that identify a system. Some sets are not
allowed because they are used by SAP. They are informed when the system
is installed.

•
  TCP/IP



It
is the most widely used transport protocol for open systems. R/3 clients
and servers communicate using TCP/IP.

•
  Telnet



It
provides terminal access to hosts using TCP/IP protocol. It is a well-known
command among Systems Administrators.

•
  Token
  Ring



It
is a LAN architecture with ring topology. The transmission speed is 4 MBit/s
or 16 MBit/s. This involves a 'free token' which circles the loop picking
up transmissions. The receiver station places a confirmation bit into the
busy token. As soon as the busy token reaches the sender station again,
it is converted back to a free token and sent on to the next station.

•
  Transport



It
is a request to transport objects from the software development environment,
identified as the source system, to the specified target system.

•
  WAN (Wide
  Area Networks)



They
are normally operated either by the telephone company or by private companies
that offer leased lines, switched lines or packet lines.

•
  Work process



Work
processes perform the bulk of the processing carried out by SAP systems.
They perform dialog steps in user transactions and carry out updates, lock
management, printing services, and so on.

•
  Workbench



The
ABAP/4 Workbench, a graphical programming environment, is used to create
application programs. The programming tools are accessed using buttons,
dialogs and windows.

•
  Workflow



It
consists of time and logical sequence of work items, which are precessed
by human agents or mechanical processing units.

•
  X.25



It
is a standardized network access protocol for the packet switching network.
The maximum transmission speed is 64 KBit/s.

---

Thanks to Ricardo
Fernandes de Miranda for submitting this document.

BSOD each time you boot windows?

Symptoms:
1. Machine show Blue screen of death (BSOD) each time Windows Start
2. Failed to boot in Safe Mode because BSOD appears as well.
3. You start to panic.


Solution:
1. Reboot machine and enable CD Boot
2. Insert Windows installation disk
3. Boot from CD Rom
4. Press R to repair a windows installation
5. In the recovery console, perform "CHKDSK"
6. Restart machine.

* If Windows still fail to boot up, try reformat machine.
* It might also be caused by faulty hardware or application.

Replace RAM for Fujitsu Lifebook P5000

1. Shutdown the Laptop.
2. Remove the battery
3. You will see 3 small screw with arrows as indication.
4. Removes these screw.


5. Now turn the laptop over
6. Gently use a ruler and lift up this plastic piece



7. Once plastic piece remove, you can gently lift up the keyboard
8. You can then change the RAM.

Fracture on resistor cause by power surge

Lately, its been raining heavily. Our telephone lines past throught a surge protector. Inside there are a pair of resistors that act as a fuis.

Lucky to have them!
